Deploy with Portainer on Synology NAS (known bug)

Deploying individual Docker containers is easy on Synology NAS, either via the Docker package web interface or via the docker CLI.

Deploying complete docker-compose templates via CLI is also feasible, but for anything more you would typically switch to using something like Portainer to manage your Docker stacks, services, containers, volumes, networks, images etc.

Unfortunately, using docker stack via CLI or Portainer App templates presents a bit of a challenge on Synology NAS devices. Due to a known bug of Docker on Synology, environment parameters defined for services are not passed along to create the actual containers.

This makes using Portainer to deploy a complete stack or re-configure your services via environment variables difficult compared to other platforms...

Here are some possible work-arounds you can use:

a. Update the stack template with the right template values whenever you want to (re-)deploy

version: '3.6'
services:
  web:
    #...
    ports:
      - "5080:5080"
    environment:
      HOST_PORT: 5080
      FLASK_PORT: 5080
      FLASK_HOST: "0.0.0.0"
      APP_NAME: "Template"
      #...

b. Use docker configs in your template to pass along a .env file, and override the image CMD if needed

version: '3.6'
services:
  web:
    #...
    #env_file: /data/container_env/env.quickstart-python
    command: sh -c '. .env && gunicorn -c gunicorn.conf.py app:app'
    configs:
      - source: env_config
        target: /app/.env
        mode: 0755
configs:
  env_config:
    # path from portainer perspective, where /data is a bind mount from /volume1/docker/portainer on the host
    file: /data/container_env/env.quickstart-python

with /data/container-env a folder you create on the portainer /data volume (or the corresponding host directory) once to hold the environment variables for all deployments. One draw-back here is that whenever the configuration changes, you need to change the name of the config as well.

c. Use docker volumes in your template to mount an env/ folder, and override the image CMD if needed

version: '3.6'
services:
  web:
    #...
    #env_file: /data/container_env/env.quickstart-python
    volumes:
      - portainer-env:/app/env
    command: sh -c '. /app/env/env.quickstart-python && gunicorn -c gunicorn.conf.py app:app'
volumes:
  portainer-env:
    external: true

with portainer-env a docker volume you create once to hold the environment variables for all deployments, e.g. as a bind mount of some directory on the host, or as a separate docker volume.

version: '3.6'
volumes:
  portainer-env:
    driver: local
    driver_opts:
       o: bind
       type: none
       device: /volume1/docker/portainer/container_env
